XANTREX - Prosine 1800i

Electrical Specifications

• Output power : 1800 watts
• Surge rating : 2900 watts
• Peak output current : 20 A
• Output voltage (at no load) : 230 VAC +/-3%
• Output voltage (over full load and battery voltage range) : 230 VAC RMS -10%/+4%
• Output frequency : 50+/-0.05 (crystal controlled)
• Output waveform : True sine wave (<3% THD)
• Peak efficiency (12 V/24 V) : 90%
• No load power draw (search mode) : <1.5 W
• No load power draw (idle mode) : <22 W
• Input voltage range (12 V/24 V) : 10 – 16 VDC / 20 – 32 VDC
• Transfer relay rating (hardwire/transfer relay models) : 10 A
• Transfer time AC to inverter and inverter to AC : Max 2 cycles (typically 1 cycle) <2.5 seconds with Powersave "ON"

General Specifications

• Operating temperature range : 32 F – 140 F (0°C – 60°C)
• Storage temperature range : -22°F – 158°F (-30°C – 70°C) Hardwire
• AC output types : Hardwire with transfer relay  Schuko AC receptacle
• LCD display panel : Removable; can be mounted remotely (requires remote interface kit)
• Recommended DC fuse (12 V model) : 300 A (depending on applicable installation codes)
• Recommended DC fuse (24 V model) : 100 A (depending on applicable installation codes)

Regulatory Approvals

• CE Mark – Low Voltage Directive (EN50091-1)
• EMC Directive (EN50091-2)
• e-Mark – Automotive EMC Directive 95/54/EC
